How to Choose a Custom LED Driver?

When selecting a custom LED driver, several key factors should be considered:

Define Your Requirements

Functional Requirements: Determine whether the mirror requires additional functions such as defogging, smart control features (e.g., touchscreen operation, Bluetooth connectivity), or environmental display features. Different functions will impact the power, voltage, and current requirements of the custom LED driver.

Lighting Requirements: Based on the usage scenario and lighting needs of the mirror, decide on the number, length, and power of the LED strips, which will then guide the selection of the custom LED driver's output power. For instance, a mirror intended for makeup application may need brighter, more uniform lighting, while a mirror used for daily purposes may have lower lighting requirements.

Understand the LED Strip Parameters

• Voltage: LED strips typically operate at standard voltages such as 12V or 24V. If the LED strip specifies a particular voltage, ensure that the custom LED driver matches that output voltage.




• Current: The required current can be calculated based on the LED strip's power and voltage. For example, for a 12V LED strip with a power rating of 24W, use the formula P=UI (where P is power, U is voltage, and I is current). By calculating, I = P/U = 24W / 12V = 2A. Thus, you would need a custom LED driver capable of providing 2A of current.




• Quantity and Connection Method: If multiple LED strips are used, consider how they will be connected, whether in series, parallel, or a matrix configuration. Different connection methods will require different output voltage and current specifications from the custom LED driver.

Consider the Type of Custom LED Driver

• Constant Current Driver: This type of driver provides a fixed current to the LEDs, ensuring stable light output, higher reliability, and better efficiency. However, constant current drivers tend to be more expensive and may need to be adjusted or replaced when the number of LEDs changes.




• Constant Voltage Driver: This type provides a fixed voltage to the LEDs and is generally less expensive. It's easier to replace when changing LEDs, but it requires higher protection against overcurrent. Voltage fluctuations could impact current stability, which may affect the LED's lifespan and light output.

Consider Environmental Factors

• Installation Location: If the mirror is installed in a damp environment, such as a bathroom, you should select a custom LED driver with waterproof and moisture-resistant features to prevent short circuits and damage.

• Temperature: Choose a custom LED driver that can operate effectively within the temperature range of the environment where the mirror is installed. High-temperature environments may require drivers with better heat dissipation capabilities or higher temperature ratings.

Chalaat's custom LED driver is designed to meet the specific lighting needs and requirements of various applications, offering excellent efficiency, stability, and broad compatibility. Whether it's smart dimming, waterproof designs, or ultra-thin solutions, Chalaat provides precisely matched solutions that enhance the performance of lighting products, making it an ideal choice for both commercial and residential customization.
